廣東佛山樂從C型鋼生產廠家,C型鋼檁條,C型槽價格,可定做Q345B材質高鍍鋅層高強度鋼

當前位置：網站首頁 » 倉儲庫存 » 廣東佛山樂從C型鋼生產廠家,C型鋼檁條,C型槽價格,可定做Q345B材質高鍍鋅層高強度鋼

廣東佛山樂從C型鋼生產廠家,C型鋼檁條,C型槽價格,可定做Q345B材質高鍍鋅層高強度鋼
文章作者：admin 更新日期：2018-09-14 02-27-28

廣東佛山樂從C型鋼生產廠家,C型鋼檁條,C型槽價格,可定做Q345B材質高鍍鋅層高強度鋼

C型鋼規格型號及技術參數

尺寸

面積

重量

重心

彎心

斷面參數

（mm）

CM2

Kg/m

CM

CM

CM4

CM3

CM

CM4

CM

CM3

CM3

H

B

C

t

A

m

ex

ey

e0

Ix

Wx

rx

ly

ry

Wymax

Wymin

80

45

10

2.00

3.57

2.80

1.71

3.75

3.93

31.98

8.53

2.99

10.08

1.68

5.91

3.61

80

45

10

2.30

4.05

3.18

1.70

3.75

3.89

35.78

9.54

2.97

11.18

1.66

6.56

4.00

80

45

10

2.50

4.36

3.42

1.70

3.75

3.86

38.18

10.18

2.96

11.85

1.65

6.97

4.23

80

45

10

2.75

4.73

3.72

1.70

3.75

3.83

41.03

10.94

2.94

12.63

1.63

7.44

4.51

80

45

10

3.00 3.00

5.10

4.01

1.69

3.75

3.80

43.70

11.65

2.93

13.33

1.62

7.87

4.75

100

50

15-20

2.00

4.47

3.51

1.86

5.00

4.38

69.62

13.92

3.95

16.44

1.92

8.86

5.23

100

50

15-20

2.30

5.08

3.99

1.85

5.00

4.34

78.35

15.67

3.93

18.35

1.90

9.91

5.83

100

50

15-20

2.50

5.48

4.30

1.85

5.00

4.32

83.92

16.78

3.91

19.55

1.89

10.57

6.21

100

50

15-20

2.75

5.97

4.69

1.85

5.00

4.28

90.63

18.13

3.90

20.96

1.87

11.34

6.65

100

50

15-20

3.00

6.45

5.07

1.84

5.00

4.25

97.03

19.41

3.88

22.27

1.86

12.07

7.06

120

50

15-20

2.00

4.87

3.82

1.71

6.00

4.11

106.94

17.82

4.69

17.57

1.90

10.27

5.34

120

50

15-20

2.30

5.54

4.35

1.71

6.00

4.08

120.58

20.10

4.66

19.62

1.88

11.49

5.96

120

50

15-20

2.50

5.98

4.70

1.71

6.00

4.05

129.33

21.55

4.65

20.91

1.87

12.26

6.35

120

50

15-20

2.75

6.52

5.12

1.70

6.00

4.02

139.89

23.31

4.63

22.43

1.85

13.17

6.80

120

50

15-20

3.00

7.05

5.54

1.70

6.00

3.99

150.02

25.00

4.61

23.85

1.84

14.02

7.23

140

60

15-20

2.00

5.67

4.45

1.98

7.00

4.77

173.04

24.72

5.53

28.65

2.25

14.49

7.12

140

60

15-20

2.30

6.46

5.07

1.97

7.00

4.73

195.70

27.96

5.50

32.11

2.23

16.28

7.97

140

60

15-20

2.50

6.98

5.48

1.97

7.00

4.71

210.33

30.05

5.49

34.31

2.22

17.41

8.51

140

60

15-20

2.75

7.62

5.98

1.97

7.00

4.68

228.10

30.59

5.47

36.92

2.20

18.77

9.16

140

60

15-20

3.00

8.25

6.48

1.96

7.00

4.64

245.28

35.04

5.45

39.40

2.18

20.06

9.76

160

60

15-20

2.00

6.07

4.76

1.85

8.00

4.54

236.56

29.57

6.24

29.96

2.22

16.17

7.22

160

60

15-20

2.30

6.92

5.43

1.85

8.00

4.50

267.81

33.48

6.22

33.60

2.20

18.16

8.09

160

60

15-20

2.50

7.48

5.87

1.85

8.00

4.48

288.05

36.01

6.21

35.90

2.19

19.43

8.64

160

60

15-20

2.75

8.17

6.42

1.84

8.00

4.45

312.66

39.08

6.19

38.64

2.17

20.95

9.30

160

60

15-20

3.00

8.85

6.95

1.84

8.00

4.41

336.52

42.07

6.17

41.24

2.16

22.40

9.92

160

70

15-20

2.00

6.47

5.08

2.24

8.00

5.42

261.52

32.69

6.36

43.42

2.59

19.40

9.12

160

70

15-20

2.30

7.38

5.79

2.23

8.00

5.38

296.41

37.05

6.34

48.82

2.57

21.85

10.24

160

70

15-20

2.50

7.98

6.27

2.23

8.00

5.35

319.05

39.88

6.32

52.26

2.56

23.42

10.96

160

70

15-20

2.75

8.72

6.85

2.23

8.00

5.32

346.66

43.33

6.30

56.38

2.54

25.31

11.81

160

70

15-20

3.00

9.45

7.42

2.22

8.00

5.29

373.50

46.69

6.29

60.32

2.53

27.12

12.63

180

70

15-20

2.00

6.87

5.39

2.11

9.00

5.19

343.90

38.21

7.08

45.14

2.56

21.35

9.24

180

70

15-20

2.30

7.84

6.16

2.11

9.00

5.15

390.09

43.34

7.05

50.76

2.54

24.06

10.38

180

70

15-20

2.50

8.48

6.66

2.11

9.00

5.13

420.11

46.68

7.04

54.34

2.53

25.79

11.11

180

70

15-20

2.75

9.27

7.28

2.10

9.00

5.09

456.77

50.75

7.02

58.64

2.51

27.87

11.98

180

70

15-20

3.00

10.05

7.89

2.10

9.00

5.06

492.47

54.72

7.00

62.74

2.50

29.87

12.81

200

75

15-20

2.00

7.47

5.86

2.19

10.00

5.40

459.63

45.96

7.85

55.19

2.72

25.25

10.39

200

75

15-20

2.30

8.53

6.70

2.18

10.00

5.37

521.93

52.19

7.82

61.13

2.70

28.48

11.68

200

75

15-20

2.50

9.23

7.25

2.18

10.00

5.34

562.51

56.25

7.81

66.58

2.69

30.55

12.51

200

75

15-20

2.75

10.10

7.93

2.18

10.00

5.31

612.18

61.22

7.79

71.59

2.67

33.05

13.51

200

75

15-20

3.00

10.95

8.60

2.17

10.00

5.28

660.66

66.07

7.77

77.03

2.65

35.46

14.46

250

75

15-20

2.00

8.47

6.65

1.94

12.50

4.93

776.45

62.12

9.58

59.02

2.64

30.43

10.62

250

75

15-20

2.30

9.68

7.60

1.94

12.50

4.90

882.83

70.63

9.55

66.46

2.62

34.32

11.95

250

75

15-20

2.50

10.48

8.23

1.93

12.50

4.87

952.29

76.18

9.53

71.22

2.61

36.82

12.80

250

75

15-20

2.75

11.47

9.01

1.93

12.50

4.84

1037.50

83.00

9.51

76.95

2.59

39.84

13.82

250

75

15-20

3.00

12.45

9.78

1.93

12.50

4.81

1120.90

89.67

9.49

82.43

2.57

42.74

14.80

300

80

15-20

2.5

12.5

9.61

1.89

15.00

4.462

1588.59

105.9

11.38

93.48

2.76

48.08

15.30

300

80

15-20

3

14.64

11.49

1.89

15.00

4.54

1889.75

125.98

11.36

109.92

2.74

56.00

18.16

300

100

15-20

2.75

14.54

11.41

1.90

15.00

6.00

1982.84

132.18

11.67

176.71

3.48

67.70

23.91

300

100

15-20

3

15.84

12.43

1.90

15.00

6.10

2154.38

143.62

11.66

191.18

3.47

73.20

25.87

 二、幾何尺寸：

C型檁條斷面尺寸

型號

斷面尺寸

h

備注

H

B

B

C

t

C80

80

40

40

15-20

2.0-3.0



以上規格C型鋼材質均采用Q195-Q235

（可沖中孔）

C100

100

50

50

15-20

2.0-3.0



C120

120

50

50

15-20

2.0-3.0

孔距可調

C140

140

50

50

15-20

2.0-3.0

孔距可調

C160

160

50

50

15-20

2.0-3.0

孔距可調

C160

160

60

60

15-20

2.0-3.0

孔距可調

C180

180

60

60

15-20

2.0-3.0

孔距可調

C200

200

60

60

15-20

2.0-3.0

孔距可調

C220

220

60

60

15-20

2.0-3.0

孔距可調

C220

220

70

70

15-20

2.0-3.0

孔距可調

C250

250

70

70

15-20

2.0-3.0

孔距可調

C250

250

80

80

15-20

2.0-3.0

孔距可調

C300

300

80

80

15-20

2.0-3.0

孔距可調






板材厚度明細表

板材名稱

厚度

板材名稱

厚度

板材名稱

厚度

板材名稱

厚度

鍍鋅板

0.17

國產

（彩涂板）

0.23

國產

（彩涂板）

0.35

鋁板

0.3

0.2

0.25

0.4

0.35

0.23

0.28

0.45

0.4

0.25

0.326

0.5

0.45

0.27

0.376

0.6

0.5

0.3

0.426

0.7

0.6

0.35

0.476

0.8

0.7

0.4

0.5

1.0

0.8

0.45

0.526

1.2

0.9

0.47

0.6

空白

1.0

0.5

0.7

1.5

0.6

0.8

2.0

0.65

進口

（彩涂板）

0.286

2.5

0.7

0.326

3.0

0.75

0.376

空白

0.8

0.426

0.85

0.476

0.9

0.526

1.0

0.576

1.1





1,槽80x40x15x2.0,80,40,15,2,14.52,33.6,347,341600,77900,462,112900000

2,槽100x50x15x2.5,100,50,15,2.5,17.06,39.4,523,813400,171900,1090,352800000

3,槽120x50x20x2.5,120,50,20,2.5,17.06,40.3,598,1294000,209600,1246,660900000

4,槽120x60x20x3.0,120,60,20,3,21.06,48.7,765,1706800,373600,2296,1153200000

5,槽140x60x20x3.0,140,60,20,3,19.64,46.1,825,2454200,394900,2476,1589800000

6,槽150x50x20x1.6,150,50,20,1.6,15.24,27.2,422,1362930,141870,360,663830000

7,槽150x50x20x2.0,150,50,20,2,15.24,27.2,528,1703660,177330,700,629790000

8,槽150x50x20x2.5,150,50,20,2.5,15.24,27.2,660,2129580,221660,1380,1037230000

9,槽150x50x20x3.0,150,50,20,3,15.24,27.2,792,2555490,266000,2380,1244530000

10,槽150x60x20x1.6,150,60,20,1.6,19,45,451,1514130,214620,390,995870000

11,槽150x60x20x2.0,150,60,20,2,19,45,564,1892660,268520,750,1244840000

12,槽150x60x20x2.5,150,60,20,2.5,19,45,705,2365830,335650,1470,1556050000

13,槽150x60x20x3.0,150,60,20,3,19,45,846,2838990,402780,2540,1867260000

14,槽160x60x20x2.0,160,60,20,2,18.41,44,582,2195200,274190,780,1417250000

15,槽160x60x20x2.5,160,60,20,2.5,18.41,44,728,2744000,342730,1520,1771660000

16,槽160x60x20x3.0,160,60,20,2.5,18.41,44,874,3292800,411280,2620,2125880000

17,槽160x70x20x3.0,160,70,20,3,22.24,52.5,742,3736400,604200,2836,3070500000

18,槽180x60x20x2.0,160,60,20,2,17.33,42.1,619,2861760,284520,830,1804350000

19,槽180x60x20x2.5,160,60,20,2.5,17.33,42.1,774,3602200,355650,1610,2255440000

20,槽180x60x20x3.0,160,60,20,3,17.33,42.1,926,4322640,426780,2790,2706520000

21,槽180x70x20x2.0,180,70,20,2,21.1,50,687,3439300,451800,870,2554750000

22,槽180x70x20x2.2,180,70,20,2.2,21.1,50,752,3749000,489700,1254,2856540000

23,槽180x70x20x2.5,180,70,20,2.5,21.1,50,848,4202000,544200,1710,3193430000

24,槽180x70x20x3.0,180,70,20,3,21.1,50,983,4730880,609240,2950,3832120000

25,槽200x65x20x2.0,200,65,20,2,18.1,44,673,3850560,353370,900,2693490000

26,槽200x65x20x2.5,200,65,20,2.5,18.1,44,842,4813200,441720,1760,3366860000

27,槽200x65x20x3.0,200,65,20,3,18.1,44,1010,5775840,530060,3030,4040230000

28,槽200x70x20x2.0,200,70,20,2,20,44,727,4400400,467100,920,3185500000

29,槽200x70x20x2.2,200,70,20,2.2,20,48,796,4798700,506400,1200,3548520000

30,槽200x70x20x2.5,200,70,20,2.5,20,48,898,5382100,562700,1800,3981870000

31,槽200x70x20x3.0,200,70,20,3,20,48,1037,6027840,629540,3120,4778240000

32,槽220x70x20x2.5,220,70,20,2.5,19,46,910,6263600,539850,1900,4877150000

33,槽220x70x20x3.0,220,70,20,3,19,46,1092,7516320,647820,3280,5852580000

34,槽220x70x20x3.2,220,70,20,3.2,19,46,1165,8017410,691000,3980,6242670000

35,槽220x75x20x2.0,220,75,20,2,20.8,51,787,5744500,568800,1290,4109230000

36,槽220x75x20x2.2,220,75,20,2.2,20.8,51,862,6268500,617100,1760,4609302000

37,槽220x75x20x2.5,220,75,20,2.5,20.7,51,973,7037600,686600,1950,5707180000

38,槽220x75x20x3.0,220,75,20,3,20.7,51,1119,7621240,761170,3360,6848620000

39,槽220x75x20x3.2,220,75,20,3.2,20.7,51,1194,8342660,811910,4080,7305200000

40,槽250x70x20x2.5,250,70,20,2.5,17.6,44,978,8441830,560030,2040,6427600000

41,槽250x70x20x3.0,250,70,20,3,17.6,44,1174,10130190,672040,3530,7713120000

42,槽250x70x20x3.2,250,70,20,3.2,17.6,44,1252,10805540,716840,4280,8227320000

43,槽250x80x20x2.5,250,80,20,2.5,21,51,1024,9098080,766550,2140,8721010000

44,槽250x80x20x3.0,250,80,20,3,21,51,1229,10917690,919850,3690,10465300000



各行數字含義（以最后一行為例）：

槽250x80x20x3.0：

截面高度H=250mm；

截面寬度B=80mm；

卷邊寬度C=20mm；

厚度t=3mm；

Y軸距離z0=21mm；

偏心距e=51mm；

截面面積A=1229mm2；

慣性矩Ix=10917690mm4；

慣性矩Iy=919850mm4；

截面模量Wx=87342mm3；

截面模量Wy=15591mm3；

回轉半徑ix=94.3mm；

回轉半徑iy=27.4mm；

抗扭慣性矩It=3690mm4；

扇形慣性矩Iw=10465300000mm4；

單位重量=A*7850/1000000=9.648Kg/m



上一篇：無縫鋼管,20#無縫管,GB5310 20G無縫鋼管,廣東樂從無縫管批發
下一篇：廣東佛山樂從H型鋼批發,Q235H型鋼價格,Q345BH型鋼廠家直銷
